產品型號

JS-G(普通型)9611/9631/5421/3841     \JS-G(梯度型)9612/9632/5422/3842

樣本容量Capacity

 (96×0.2ml) , (96×0.2ml+77×0.5ml) ,( 54×0.5ml) ,( 384well)

溫度范圍Temperature Range

                                0～99.9℃

髙至升溫速率 Heating Rate

                                  4℃/s

 髙至降溫速率 Cooling Rate

                                   4℃/s

溫度均勻性 Uniformity

                                  ≤±0.3℃

溫度[accuracy]性 Accuracy

                                  ≤±0.2℃

溫度顯示分辨率Display Resolution

                                   0.1℃

溫度控制方式 Temperature Control

                                 Block\Tube

變溫速率可調 Ramping Rate Adjustale

                                 0.1～4℃

梯度溫度均勻性 Gradient Uniformity

                 /                            \≤±0.3℃

梯度[accuracy][accuracy]性Gradient Accuracy

               /                              \ ≤±0.2℃

梯度溫度范圍 Gradient Temp. Range

              /                               \ 30～99.9℃

梯度設置范圍 Gradient Spread

             /                                \  1～30℃

熱蓋溫度范圍 Hot Lid Temperature

                                    30～110℃

熱蓋高度調節 Hot Lid Height Adjustale

                            無級可調 Stepless Adjustable

程序存儲數量 Number of Programs

                                       200

程序髙至段數 Max.No.of Segment

                                        9

程序髙至步驟 Max.No.of Step

                                        9

程序髙至循環數 Max.No.of Cycle

                                        99

時間遞增/遞減 Time Increment/Decrement

                                 1 Sec ～ 9 Min 59 Sec

 度遞增/遞減 Temp. Increment/Decrement

                                    0.1～9.9℃

程序暫停功能 Pause Funcation

                                        有 Yes

掉電數據保護 Auto Data Protection

                                        有 Yes

溫度曲線顯示 Graphical Display

                                        有 Yes

4℃保溫 Hold at 4℃

                                     無限長 Forever

語言設置功能 Language

                                       中文/English

 液晶顯示屏 LCD

                                   5.7inch，320×240 pels

 通訊接口 Communication

                                     USB2.0 , RS232

輸入電源 Power Supply

                            85～264VAC , 50～60Hz , 600 W

 產品尺寸 Dimensions

392mm×262mm×252mm (L×W×H)產品凈重 Weight10kg
